CCI ESS (AIR COOLING)

Energy
215.04KWh-261.25KWh

Application:

Community
Commercial
Industrial
Charging Station

Certifications:

IEC62619 IEC61000 IEC62477
UL1973 UL9540A
Model
Energy Bank EXEN-100-215
Energy Bank EXEN-120-241
TRACK EXEN-100-233-Y
TRACK EXEN-120-261-Y

Related Products

72174207-280Ah

72174207-314Ah

Parameters

Model EnergyBankEXEN-100-215 EnergyBankEXEN-120-241 TRACKEXEN-100-233-Y TRACKEXEN-120-261-Y
Output (On Grid)
Power 100kW 120kW 100kW 120kW
AC Voltage 400V
AC Frequency 50/60Hz
Wiring 3/N/PE
Battery (DC)
Battery Type LFP280 LFP314 LFP280 LFP314
Energy 215.04kWh 241.15kWh 232.96kWh 261.25kWh
Voltage 672V~864V 728V~936V
Module Qty 16S1P*15 52S1P*5
Cooling Air Con + Forced Air Liquid
General
Dimension W1650mm D1000mmH2350mm W1300mm D1300mmH2300mm
Net Weight 2450kg 2750kg 2650kg 3000kg
Fire System HFC-227ea
Installation Outdoor Standalone
Op Temp. -25°C~55°C
IP Level IP54
Communication RS485/LAN
Certifications IEC62619/IEC61000/IEC62477/UL1973/UL9540A/UN38.3

*All rights reserved by Shenzhen Exencell New Energy Technology Co., Ltd.
The parameters included in this datasheet are subject to change without notice.
