CONTAINER BESS (WITH PCS)
Energy
1290KWh-3376KWh
Application：
Utility
Microgrid
Charging Station
Wind & Solar Power
Certifications：
IEC62619
UL1973 UL9540A
Model
EXEN-630-1290
EXEN-630-1447
EXEN-1260-3010
EXEN-1260-3376
Related Products
Parameters
Model EXEN-630-1290 EXEN-630-1447 EXEN-1260-3010 EXEN-1260-3376 Container 20ft 20ft 40ft 40ft AC Spec Power 630kW 1260kW Voltage 400V AC Frequency 50HZ Wiring 3P4W+PE DC Spec Cell Type LFP280 LFP314 LFP280 LFP314 Voltage 768V 768V 768V 768V Pack Config 240S1P*6 240S1P*14 Energy 1290kwh 1447kwh 3010kWh 3376kWh General IP Level IP54 Cooling Air Con + Forced Air Fire System HFC-227ea/PERFLUORO Op Temp. -15°C~50°C Dimension 6058mmx2438mmx2896mm 12192mmx2438mmx2896mm Weight 17T 17T 17T 17T Communication RS485, Ethernet, 4G
| Model | EXEN-630-1290 | EXEN-630-1447 | EXEN-1260-3010 | EXEN-1260-3376 |
| Container | 20ft | 20ft | 40ft | 40ft |
| AC Spec | ||||
| Power | 630kW | 1260kW | ||
| Voltage | 400V | |||
| AC Frequency | 50HZ | |||
| Wiring | 3P4W+PE | |||
| DC Spec | ||||
| Cell Type | LFP280 | LFP314 | LFP280 | LFP314 |
| Voltage | 768V | 768V | 768V | 768V |
| Pack Config | 240S1P*6 | 240S1P*14 | ||
| Energy | 1290kwh | 1447kwh | 3010kWh | 3376kWh |
| General | ||||
| IP Level | IP54 | |||
| Cooling | Air Con + Forced Air | |||
| Fire System | HFC-227ea/PERFLUORO | |||
| Op Temp. | -15°C~50°C | |||
| Dimension | 6058mmx2438mmx2896mm | 12192mmx2438mmx2896mm | ||
| Weight | 17T | 17T | 17T | 17T |
| Communication | RS485, Ethernet, 4G | |||
*All rights reserved by Shenzhen Exencell New Energy Technology Co., Ltd.
The parameters included in this datasheet are subject to change without notice.
